Sony HXR-MC2500 1/4-inch Exmor R CMOS Sensor HD / SD NXCAM Camcorder

Home > Sony > AVCHD & NXCAM > HXR-MC2500

7% Goods Service Tax (GST) will be imposed over the total invoice value if purchased locally in Singapore. However if you are a tourist visiting Singapore, this GST amount can be refunded at the Changi International Airport Departure Hall GST Refund Centre before departure with goods within 30 Days from the date of purchase. Please note that only Tourists who have met the Tourist Refund Scheme's conditions and eligibility criteria can claim for the GST refund. Please visit: https://www.iras.gov.sg/IRASHome/GST/Consumers/Tourist-Refund-Scheme/ for GST Guide for Visitors on Tourist Refund Scheme.


Sony HXR-MC2500 NXCAM Camcorder
Product Code: HXRMC2500
Discontinued
review button

  • Optional Accessories
    Li-Ion Battery
    Anton Bauer NP-F976
    NP-F976
    6600 mAh Li-Ion Battery
    Anton Bauer NP-F976
  • Optional Accessories
    Sony Headphone
    Sony MDR-7506
    MDR-7506
    Buy Sell Sale Sony MDR-7506
HXR-MC2500: Overview
The Sony HXR-MC2500 provides a professional look and shooting style which is ideal for weddings, corporate communications or education facilities. While light and easily portable, its full Shoulder Mount design means your clients immediately know you mean business.

Workflow flexibility is enhanced by the ability to record directly onto a removable memory card or a 32GB internal flash memory storage system in High Definition or Standard Definition. With this combination of the internal flash memory and memory card allows recording functions such as "Relay" and "Simultaneous" are available. When Sony's L-Series Info Lithium battery NP-F970 (optional) is used, the Sony HXR-MC2500 is capable of continuous long recording of up to 14 hours- perfect for those occasions where you don't want to stop recording, such as weddings or business conferences.

NOTE: Depending on your region, the Sony HXR-MC2500 is available in PAL or NTSC models to ensure the best possible performance. See specification for more details

Features

Wide-angle G Lens
The Sony HXR-MC2500 comes equipped with a sophisticated G Lens that incorporates Sony's unique optical design technology and quality control, delivering exceptional performance on a par with some of the best lenses in the industry.

The Sony HXR-MC2500 itself is optimized to perfectly complement the G Lens with an advanced image sensor and Sony's famous image processing technology. This improves picture performance whether zooming in on the action, or getting a perspective on the big picture with a 26.8mm* lens offering the widest angles in this class of camera, which enables wide-angle shooting even in tight spaces.
*35mm or equivalent



Highly-sensitive Exmor™ R CMOS sensor and built-in LED light
The Sony HXR-MC2500 is capable of shooting clearly even in low-light or indoor environments. Its highly-sensitive Exmor™ R CMOS sensor adopts a back-illuminated technology that enables the image sensor to utilize incidental light more efficiently, helping the video-grapher to achieve rich image quality even during low-light shooting situations. Moreover, the Sony HXR-MC2500 is also equipped with a convenient built-in LED light for valuable extra illumination when needed.

Wide angle view, high contrast OLED viewfinder and 3-inch wide LCD panel
The Sony HXR-MC2500 is equipped with an OLED Tru-Finder™ electronic viewfinder, offering a high resolution of approximately 1.44 million dots with high contrast levels. Sony's proprietary viewfinder technologies allow for better tonal reproduction and more detailed picture information when shooting. In addition, there is also the built-in 3-inch wide high resolution LCD panel (approximately 0.92 million dots) for crisp and bright views.

Wi-Fi/NFC functions for seamless connection to smart phones
The Sony HXR-MC2500 can connect to mobile devices such as smart phones or tablets via a Wi-Fi connection, enabling monitoring and remote control functions such as start/stop recording, zoom control, iris control and touch auto focus. Furthermore, it is also NFC-capable (Near Field Communications) to allow easy, one-touch wireless connections to compatible mobile devices.

Multi-Interface (MI) Shoe
The Sony HXR-MC2500 MI Shoe expands your options to use accessories without cables, such as the UWP-D11 wireless microphone receiver and XLR audio input by XLR adapter.

Specifications
General
Mass Approx 2.80kg (body)
Approx. 6lb 2.8oz (body)
Approx. 3.10kg (with lens hood, Lens Cap, Microphone, Eyecup, Shoe Cap, NP-F570 battery)
Approx. 6lb 13.3oz (with lens hood, Lens Cap, Microphone, Eyecup, Shoe Cap, NP-F570 battery)
Dimension
(W x H x D)
265.0 x 235.0 x 455.0 mm (body)
10 1/2 x 9 3/8 x 18 inches (body)
265.0 x 240.0 x 460.0 mm (With the accessories (lens hood, Lens Cap, Microphone, Eyecup), excluding the grip belt and including the projecting parts)
10 1/2 x 9 1/2 x 18 1/8 inches (With the accessories (lens hood, Lens Cap, Microphone, Eyecup), excluding the grip belt and including the projecting parts)
Power requirements 7.2V (battery pack); 8.4V (AC Adaptor)
Power consumption Approx. 3.3 W (with EVF On, Video light Off)
Approx. 3.3 W (with LCD monitor On, Video light Off)
Operating temperature 0°C to 40°C (32°F to 104°F)
Storage temperature -20°C to +60°C (-4°F to +140°F)
Battery operating time Approx. 285 min with NP-F570 battery (video light Off)
Approx. 135 min with NP-F570 battery (video light On)
Recording format Video Format HD MPEG4-AVC / H. 264 AVCHD format Ver.2.0 compatible
Video Format SD DV(AVI)
Audio Format HD Linear PCM 2ch, 16bit, 48kHz / Dolby Digital 2ch, 16bit, 48kHz
Audio Format SD Linear PCM 2ch, 16bit, 48kHz
Recording frame rate (NTSC) - HD PS(28Mbps) 1920 x 1080/60P, 16:9
FX(24Mbps) 1920 x 1080/60i, 30p,24p, 16:9, 1280 x 720/60p, 16:9
FH(17Mbps) 1920 x 1080/60i, 30p,24p, 16:9, 1280 x 720/60p, 16:9
HQ(9Mbps) 1280 x 720/60p, 16:9
(NTSC) - SD DV(25Mbps) 720 x 480/60i, 16:9, 4:3
(PAL) - HD PS(28Mbps) 1920 x 1080/50P, 16:9
FX(24Mbps) 1920 x 1080/50i, 25p, 16:9, 1280 x 720/50p, 16:9
FH(17Mbps) 1920 x 1080/50i, 25p, 16:9, 1280 x 720/50p, 16:9
HQ(9Mbps) 1280 x 720/50p, 16:9
(PAL) - SD DV(25Mbps) 720 x 576/50i, 16:9, 4:3
Recording/Playback time Approx.145min(Internal Media, PS, LPCM)
Approx.170min(Internal Media, FX, LPCM)
Approx.225min(Internal Media, FH, LPCM)
Approx.380min(Internal Media, HQ, LPCM)
Approx.140min(Internal Media, DV, LPCM)
Lens
Lens Mount Fixed
Zoom Ratio 12x (optical), servo/manual
Focal Length f = 2.9-34.8mm
equivalent to f=26.8-321.6mm on 35 mm lens(16:9)
equivalent to f=32.8-393.6mm on 35 mm lens(4:3)
Iris F1.8 - F3.4 auto/manual selectable
Focus AF/MF selectable, 10 mm to ∞ (Wide), 800 mm to ∞ (Tele)l
Image stabilizer ON(Standard/ACTIVE)/OFF selectable, shift lens
Filter Diameter M37 mm
Camera Section
Imaging Device (Type) 1/3.95 type(4.6mm) back-illuminated Exmor R CMOS Sensor
(Pixel Count) Approx.6590K pixels
Effective Picture Elements  Approx.6140K pixels(16:9)/Approx.4600K pixels(4:3)
Minimum illumination 1.4lux(MAN setting : SS 1/25sec , Iris F1.8 , Gain 33dB)
0.7lux(MAN setting : SS 1/12sec , Iris F1.8 , Gain 33dB)
Shutter speed 1/6 - 1/10,000
White balance Preset(Indoor, Outdoor, Color temperature set range:2300-15000K) Onepush A, B, Auto selectable
Gain 0, 3, 6, 9, 12, 15, 18, 21, 24, 27, 30, 33 dB, Auto Selectable
Inputs/Outputs
Composite Output BNC (x1)
Audio Output RCA pin
USB mini-AB USB2.0 Hi-speed/mass-storage/Host
Headphone Output Stereo mini jack φ3.5mm (x1)
Speaker Output Monaural
DC Input DC jack
Remote Stereo mini mini jack φ2.5mm (x1)
HDMI Output Type A (x1)
Accessory Shoe Multi Interface Shoe (x1), Cold Shoe (x2)
Monitoring
Viewfinder 1.0cm (0.39 type) OLED Approx. 1.44M dots
Built-in LCD monitor 7.5cm (3.0 type) Approx. 921K dots
Built-in Microphone
Built-in Microphone Omni-directional stereo electret condenser microphone.
Media
Internal Memory Flash Memory 32GB
Type Memory Stick Pro Duo™ and SD/SDHC/SDXC compatible
Built-in LED Light
Luminous intensity 1.0m / Approx.200 lx, 0.5m / Approx.800lx
Lighting angle Approx. 30°
Color temperature PApprox. 5,500K
Wifi
Supported format IEEE 802.11 b/g/n
Frequency band 2.4 GHz bandwidth
Security WEP/WPA-PSK/WPA2-PSK
NFC NFC Forum Type 3 Tag compliant
Supplied Accessories
- Lens cap (1)
- Shoe Cap (1)
- EVF eyecup (1)
- Microphone (1)
- Wind screen (1)
- Video Light Diffuser (1)
- USB adaptor cable (1)
- Rechargeable battery pack (NP-F570) (1)
- CD-ROM Operating instructions in PDF (1)
- Operating instructions (1)
- AC-L100C AC adaptor (1)
- AC Cable (1)
- Warranty (1)
