The
Ultimate Broadcast PTZ Camera
The AW-HN130 is a flexible
remote video production camera which
adds many innovative features to
Panasonic's previous AW-HE120/130
PTZ which has become the de facto
standard remote control camera for
educational, government, and house
of worship use and is likewise
prevalent in news, staging, sports
and reality television production.
Advanced Video
Processing for High Quality Video
With an
exceptional signal to noise ratio of
60dB (F8/2000lx minimum illumination
2.0 1x), 1000 TV lines of resolution
and such advanced features as
12-axis color correction and
Panasonic's exclusive DRS (Dynamic
Range Stretch) and Hybrid Digital
Noise Reduction, the HN130 continues
to set performance standards for
integrated pan-tilt cameras. The
HN130 includes the same new three
2.4 megapixel MOS imagers and
Digital Signal Processor (DSP) used
in Panasonic's latest broadcast
camcorders such as the AJ-PX270.
20x Zoom Lens with
Optical Image Stabilization &
Digital Extender
The
AW-HN130 professional PTZ camera
features an exceptional 20x optical
zoom range, with the ability to push
it to 10x digital zoom.
Connected – Professional
Interfacing for all sorts of remote
production
Video Outputs:
Standard professional interfaces
include HD/SD-SDI, HDMI, and SD
composite, as well as IP/Network for
single cable delivery of
high-quality content up to 1080/60p.
Serial Control:
RS-422 serial compatibility is
available for serial-based control
workflows (i.e. connection to
AW-RP50/120 or previous
controllers). RS-232 and RS-422
VISCA protocols are available when
introducing a Panasonic camera into
an existing control structure.
Network Connected |
The LAN port on the HN130
unleashes the possibilities:
•
Power of Ethernet+ (PoE+) for easier
system installation and setup.
•
Control the camera via the network
with an AW-RP50/120 hardware
controller or Panasonic software
solutions
•
Access the built-in web interface to
monitor and control all aspects of
the camera
•
Utilize a supported third-party
control system from broadcast
control systems, switchers, lecture
capture systems, AV Control system
and more
•
By default, the camera has a
built-in H.264/MJPEG encoder for 7
channels of encoding up to 25Mbps.
Pair with a supported hardware or
software decoder.
•
Built-in NDI®|HX (a technology of
NewTek Inc.) for the ultimate single
cable production workflow with
ultra-low latency video, audio,
control, tally, and power over a
single cable
Flexible
Installation & Mounting
Blend-in: The
camera is exceptionally easy to
integrate and is available in two
colors (-W: pearl white and -K:
black matte) to suit a wide range of
applications.
Ceiling
Mount: A twist-lock ceiling
mount is included as a standard
accessory.
Tripod Mount
for Mobile Production: The
HN130 is also equipped with a 1/4-20
tripod mounting screw receptacle and
a safety lanyard for use with many
mounting and grip systems.
Wall Mount: An
optional heavy-duty wall mount is
available in either black
(FEC-120WMK) or white (FEC-120WMW). |
| Color
|
Black (K) or White (W) |
| General
|
- |
| Sensor
|
1/2.86 inch 3MOS |
| Optical Zoom
|
20x |
| i.Zoom
|
- |
| DIGITAL ZOOM
|
10x |
| FOV (Horizontal)
|
60.2° (W) - 3.3° (T) |
| FOV (Vertical)
|
36.2° (W) - 1.9° (T) |
| FOV (Diagonal)
|
67.4° (W) - 3.8° (T) |
| Focus
|
Auto / Manual |
| Horizontal Resolution
|
1000 Lines |
| MINIMUM ILLUMINATION
|
2 lx |
| Gain
|
0 dB - 36 dB |
| Control
|
- |
| Power
|
PoE+ or AC |
| Installation
|
Tripod, Wall*2, Ceiling |
| Mount Position
|
Invertible |
| Standard Warranty
|
1 Year |
| PTZ
|
- |
| Pan Range
|
±175 degrees |
| Tilt Range
|
-30 to 210° |
| Pan / Tilt Speed
|
0.08°/s to 60°/s |
| Operation noise
|
NC35 or Less |
| VIDEO OUTPUT
|
- |
| LAN with built-in NDI|HX*1
|
✓ |
| 3G-SDI
|
✓ |
| HD-SDI
|
✓ |
| SD-SDI
|
✓ |
| HDMI
|
✓ |
| Composite
|
✓ |
| USB
|
- |
| Output Format
|
1080/59.94p, 1080/29.97p, 1080/23.98p, 1080/59.94i, 1080/29.97PsF,1080/23.98PsF, 720/59.94p, 480/59.94p (i)*4, 1080/50p, 1080/25p,1080/50i, 1080/25PsF, 720/50p, 576/50p (i)*4 |
| Browser (PC/Mac/Mobile) via IP)
|
✓ |
| Live Production Center (Streaming Switcher/Controller)
|
AV-HLC100 |
| Wide-Angle Tablet Control
|
AW-HEA10 |
| IR Remote Control
|
AW-RM50 |
| Compact Controller
|
AW-RP50 |
| Full-Size Controller
|
AW-RP120 |
| Remote Operation Panel
|
AK-HRP200 |
| Compact Live Switcher
|
AW-HS50N |
| Features
|
- |
| IP Live Preview
|
✓ |
| Simultaneous Multi-Stream
|
✓ |
| Image Stabilization
|
Optical |
| Night Mode (for IR)
|
✓ |
| Dynamic Range Stretch (DRS)
|
✓ |
| Audio Input / Embedding
|
✓ |
| Color Temperature Adjustment
|
✓ |
| Presets
|
Up to 100 |
| microSD Card Recording
|
- |
| High Dynamic Range (HDR)
|
- |
| Fanless Design
|
✓ |
| ND Filters
|
✓ |
| Genlock
|
✓ |
| Advanced Color Adjustment
|
✓ |
| Digital Noise Reduction (DNR)
|
✓ |
| Note
|
*1: This product is compatible with NDI|HX technology of NewTek, Inc.
*2: With appropriate right angle wall mount, available locally
*3: HDMI output only.
*4: When either 480/59.94p(i) or 576/50p(i) is selected, the output formats are delivered as follows: P signal for HDMI output and I signal for SDI output. |
| Weight (kg)
|
Approx. 3.1 kg |
| Weight (lbs.)
|
6.83 lbs |
|
