| General Specifications |
| Power Supply |
AC 200 V–240 V, 7.7 A, 50/60 Hz |
| Power Consumption |
1,510 W (0.3 W with Standby Mode set to ECO, 4 W with Standby Mode set to NORMAL) |
| DLP Chip | Panel Size |
24.4 mm (0.96 in)
diagonal (16:10 aspect ratio) |
| DLP Chip | Display Method |
DLP chip x 3, DLP projection system |
| DLP chip | Number of Pixels |
6,912,000 (1920 x 1200 x 3) pixels |
| Refresh rate |
120 Hz |
| Lens |
Optional (no lens included with this model) |
| Light Source |
Laser Diode (Laser class: Class 1)(Class 3R for US models), Light source life: 20,000 hours (NORMAL Mode, brightness decreases to approx. 50 %) / 24,000 hours (ECO Mode, brightness decreases to approx. 50 %) |
| Screen size [diagonal] |
1.78–25.4 m (70–1,000 in)
with 16:10 aspect ratio
1.78–15.24 m (70–600 in)
with the ET-D75LE8, 16:10 aspect ratio
3.05–15.24 m (120–600 in)
with the ET-D75LE95, 16:10 aspect ratio |
| Brightness |
21,000 lm (Center) / 20,000 lm |
| Center-to-corner zone ratio |
90% |
| Contrast |
20,000:1 (Full On/Full Off, Dynamic Contrast Mode: 3) |
| Resolution |
1920 x 1200 pixels |
| RGB |
fH: 15−100 kHz, fV: 24−120 Hz, dot clock: 162 MHz or less |
| Video/YC |
fH: 15.73 kHz, fV: 59.94 Hz (NTSC/NTSC4.43/PAL-M/PAL60),
fH: 15.63 kHz, fV: 50 Hz (PAL/PAL-N/SECAM) |
| Time until light output declines to 50 % |
20,000 hours (NORMAL) /24,000 hours (ECO) |
Optical axis shift
(from center of screen)| Vertical |
±55 % (±44 % with ET-D75LE6, +68 – +78 % with ET-D75LE95) (powered) |
Optical axis shift
(from center of screen)| Horizontal |
±20 % (±15 % with ET-D75LE6, ±12 % with ET-D75LE95) (powered) |
| Keystone Correction Range |
Vertical: ±40° (± 22° with ET-D75LE50, ±28° with ET-D75LE6),
Horizontal: ±15° |
Keystone Correction Range with optional
ET-UK20 Upgrade Kit |
Vertical: ±45° (± 40° with ET-D75LE10/20,
±22° with ET-D75LE50, ±28° with ET-D75LE6), Horizontal: ±40° (±15° with ET-D75LE50/6),
Up to a total of ±55° during simultaneous horizontal and vertical correction |
| Installation |
Horizontal/vertical, free 360-degree installation |
| Cabinet Materials |
Molded plastic |
| Dimensions (W x H x D) |
598 × 270 × 725 mm (23 17/32˝ x 10 5/8˝ x 28 17/32˝) (not including protruding parts) |
| Weight |
49.0 kg (108 lbs) |
| Operation noise |
46 dB |
| Operating Environment |
Operating temperature: 0–50 °C (32–122 °F)*6; Operating humidity: 10–80 % (no condensation) |
| Applicable Software |
Logo Transfer Software, Multi Monitoring & Control Software, Early Warning Software,
Geometry Manager Pro Software (ET-UK20 Upgrade Kit, ET-CUK10 Auto Screen Adjustment Upgrade Kit), Smart Projector Control |
