| General Specifications |
| Projector type |
3-Chip DLP projector |
| DLP Chip | Panel Size |
24.4 mm (0.96 in) diagonal (16:10 aspect ratio) |
| DLP Chip | Display Method |
DLP chip x 3, DLP projection system |
| DLP chip | Number of Pixels |
2,304,000 (1920 x 1200 pixels) x 3 |
| Light Source |
Laser diodes (Blue LD, Red LD) |
| Light output |
30,500 lm/32,000 lm (Center) |
| Time until light output declines to 50 % |
20,000 hours (Normal), 24,000 hours (Eco), 26,000 hours (Quiet) |
| Resolution |
4K (3840 x 2400 pixels) (Quad Pixel Drive: ON) |
| Contrast Ratio |
20,000:1 (Full On/Full Off, Dynamic Contrast [3]) |
| Screen size [diagonal] |
1.78–25.4 m (70–1,000 in), 1.78–15.24 m (70–600 in) with ET-D75LE8/ET-D3LET80, 3.05–15.24 m (120–600 in) with ET-D75LE95, 5.08–15.24 m (200–600 in) with ET-D3LEU100/ET-D3LEW200 |
| Center-to-corner zone ratio |
90% |
| Lens |
Optional (no lens included with this model) |
| Lens shift | Vertical(From the origin point of the lens mounter) |
±55 % (+78 %, +68 % with ET-D75LE95, ±48 % with ET-D3LEW200, ±44 % with ET-D75LE6/ET-D3LEW60) (powered) |
| Lens shift | Horizontal(From the origin point of the lens mounter) |
±20 % (±15 % with ET-D75LE6/ET-D3LEW60/ET-D3LEW200, ±12 % with ET-D75LE95, +25 %, 0 % with ET-D3LEU100) (powered) |
| Keystone Correction Range |
Vertical: ±45 ° (± 40 ° with ET-D75LE10/ET-D3LEW10/ET-D75LE20/ET-D3LES20, ±28 ° with ET-D75LE6/ET-D3LEW60, ±22 ° with ET-D3LEW50, ±15 ° with ET-D3LEW200, ±8 ° with ET-D3LEU100, +5 ° with ET-D75LE95),
Horizontal: ±40 ° (±15 ° with ET-D3LEW50/ET-D75LE6/ET-D3LEW60, ±5 ° with ET-D3LEU100/ET-D3LEW200, 0 ° with ET-D75LE95)
When [VERTICAL KEYSTONE] and [HORIZONTAL KEYSTONE] are used simultaneously, correction cannot be made exceeding a total of 55 °. |
| Installation |
Ceiling/floor, front/rear, free 360-degree installation |
| Terminals | SDI IN |
– |
| Terminals | HDMI In |
HDMI x 1 (Deep Color, compatible with HDCP 2.2, 4K/60p signal input) |
| Terminals | DVI-D IN |
– |
| Terminals | MULTI PROJECTOR SYNC IN |
BNC x 1 |
| Terminals | MULTI PROJECTOR SYNC OUT |
BNC x 1 |
MULTI PROJECTOR SYNC IN terminal/3D SYNC 1 IN/OUT terminal
(dual purpose) |
– |
| MULTI PROJECTOR SYNC OUT terminal/3D SYNC 2 OUT terminal (dual purpose) |
– |
| Terminals | Serial In |
D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
| Terminals | Serial Out |
D-sub 9-pin (male) x 1 for link control (RS-232C compliant) |
| Terminals | REMOTE 1 IN |
M3 stereo mini-jack x 1 for wired remote control |
| Terminals | REMOTE 1 OUT |
M3 stereo mini-jack x 1 for link control |
| Terminals | REMOTE 2 IN |
D-sub 9-pin (female) x 1 for external control (parallel) |
| Terminals | DIGITAL LINK |
RJ-45 x 1 for network and DIGITAL LINK connection (HDBaseT compliant), 100Base-TX, compatible with Art-Net, PJLink (Class 2), Deep Color, HDCP 2.2, 4K/60p signal input |
| Terminals | LAN |
RJ-45 x 1 for network connection, PJLink (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible |
| Terminals | USB |
USB connector (Type A) x 1 for optional Wireless Module (AJ-WM50 Series)/USB Memory Stick |
| Terminals | DC OUT |
USB Type A x 2 (for power supply, DC 5 V total of 2 A) |
| Terminals | Expansion slot |
SLOT 1/SLOT 2 (total two terminals, vacant) for interface boards, SLOT NX compatible |
| Power Supply |
AC 200 V–240 V (Light output will decrease when using the projector with AC 100 V to AC 120 V) |
| Power Consumption |
2,550 W (Standby: 14 W) |
| Cabinet Materials |
Molded plastic |
| Operation noise |
49 dB (Normal), 46 dB (Quiet) |
| Dimensions (W x H x D) |
Approx. 598 x 353 x 780 mm (23 17/32˝ x 13 29/32˝ x 30 23/32˝) (not including protruding parts) |
| Weight |
69.8 kg (153.9 lbs) |
| Operating Environment |
Operating temperature: 0–45 °C (32–113 °F)*7, operating humidity: 10–80 % (no condensation) |
| Applicable Software |
Logo Transfer Software, Multi Monitoring & Control Software, Early Warning Software, Smart Projector Control for iOS/Android |
