| Weight |
| Without batteries |
196g / 7oz. |
| Dimensions (W x H x D mm) |
151 x 91.5 x 31.5mm |
| Construction |
Polycarbonate ABS |
| Mounting points |
1/4”-20 screw mount. 1x top and 1x bottom |
| Power |
| Operating power |
4 - 7W |
| Compatible batteries |
NP-F series and supporting accessories. AtomX or other. |
| Input voltage (battery) |
6.2V to 16.8V |
| Battery time (based on 7.4V) |
Standby
2600mAh - 3hrs, 5200mAh - 6hrs, 7800mAh - 12hrs
Monitor
2600mAh - 1.5hrs, 5200mAh - 3hrs, 7800mAh - 6hrs |
| DC In |
via Battery Eliminator |
| Touchscreen |
| Size |
5.2” |
| Resolution |
1920 x 1080 |
| PPI |
427 |
| Aspect ratio |
16:9 native |
| Color Gamut |
REC709 HDTV |
| Look up table (LUT) support |
3D LUT (.cube format) *Extended Support planned |
| Anamorphic de-squeeze |
2x, 1.5x, 1.33x |
| Technology |
IPS panel (capacitive touch), calibration to Rec.709 with optional calibration unit |
| HDR |
| AtomHDR |
Yes |
| HDR Monitoring (Gamut) |
Sony SLog / SLog2 / SLog3, Canon CLog / CLog2 / Clog3,
Arri Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320
/ LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 /
LogCEI1000 / LogCEI1280 / LogCEI1600, Panasonic Vlog,
JVC JLog1, RED Log3G10 /RED LogFilm, FujiFilm F-log,
PQ10k, HLG, Nikon N-Log |
| HDR Monitoring (Gamma) |
Sony SGamut / SGamut3 / SGamut3.cine
Canon Cinema / DCI P3 / DCI P3+
Panasonic V Gamut
Arri Alexa Wide Gamut
Rec709 / BT.2020
JVC
RED WideGamut / RED DragonColor / DragonColor2 /
RED Color2 / RED Color3 / RED Color4 |
| Bit Depth |
10-bit (8+2 FRC) |
| Brightness |
1000nit (+/- 10%) |
| Screen Mirror/Flip |
Horizontal Flip (Selfie mode), Vertical Flip
* Landscape/Portrait mode planned for future firmware release |
| Video Input |
| HDMI |
1 x HDMI (1.4) |
| Signal |
Up to Uncompressed true 10-bit or 8-bit 422 (camera dependent) |
| Supported Formats (Video Input) |
| 4K 4096 x 2160 |
23.98p, 24p, 25p, 29.97p |
| UHD 3840 x 2160 |
23.98p, 24p, 25p, 29.97p |
| HD 1920 x 1080 |
23.98p, 24p, 25p, 29.97p, 50p, 59.94p |
| HD 1280 x 720 |
50p, 59.94p |
| Audio In (48kHz) |
| HDMI |
2ch 24-bit 48kHz |
| Audio Out |
| Headphone out |
3.5mm |
| SD Card Slot |
| Full size SD Card slot |
SD Card Slot allows LUTs to be loaded to the unit and is also used when updating AtomOS firmware |
| AtomOS |
| Monitoring Features |
Luma Waveform, RGB parade, RGB Overlay, Vectorscope, Vectorscope Zoom, Histogram, RGB Histogram, Anlaysis mode (Multiview scopes: Waveform, Histogram, Vectorscope), Focus Peaking, Zebra, False Color, Blue Only Exposure, Zoom (1:1, 2:1, 4:1), SMPTE Safe Areas, Cinema Guides, Anamorphic Desqueeze. |
|
