Clear-com FSII-SPL FreeSpeak II Splitter
Clear-com FSII-SPL is a splitter that connects
multiple FreeSpeak II transceiver antennas to an Eclipse® HX matrix (via
E-IPA-HX card) or a FreeSpeak II base station. The splitter provides up to
five antenna feeds from one antenna port and has an SFP fiber slot for fiber
connectivity
Fiber Connectivity
Using the SFP fiber slot, the FSII-SPL provides a
fiber link between the FSII-BASE-II base
station and splitter
(base-to-splitter) or it can be used to connect on legacy FreeSpeak II base
stations and the Eclipse HX frames over fiber via the E-QUE-HX interface
card (splitter-to-splitter).
IMounting Options
The splitter can be mounted on a flat surface or on
a microphone stand. LED indicators are
located on the front and back of
the unit to show status in any mounted position. Requires
an external
power supply (included).
• Functions with FSII base, FreeSpeak Edge base, Arcadia Central Station,
and E-IPA-HX cards
• Provides 5 FSII transceiver antenna feeds on 1
antenna port on FSII-BASE-II station or E-IPA-HX card
• SFP fiber slot
for fiber link to FSII-BASE-II or for connecting FSII-BASE-II
• Supports
both multi-mode and single-mode fiber
• Configure settings using DIP
switches
• LED status indicator on front and back
• Mic stand or wall
mount orientation (metric and imperial threads)
• Connections
Transceiver Antenna: 5 Ethercon RJ45, each with yellow LED indicators on
front and back
Matrix: 1 Ethercon RJ45, with yellow LED indicator
on front and back
Fiber: 1 SFP port
• Power
Splitter: Requires external power supply (included)
Transceiver
Module: Provides power to modules via RJ45 connections
•
Mounting Options
Wall Mount with 4 mounting points Mic
Stand Mount (metric and imperial threads)
• Environmental
IP63 water resistance for outdoor use +32° to +122°F (0° to
+50°C)
• Dimensions
1.65 x 8.75 x 7.73in
(HxWxD)
(42 x 223 x 197mm)
• Weight
24.5oz (0.69kg)
